旋转拨码开关-Sungmun旋转编码开关,轻触开关,Snaptron锅仔片厂家

Specification
1. Rating : 25mA, 12V DC (Switching)
25mA, 24V DC (None-Switching)
2. Contact Resistance : 100mΩ Max
3. Insulation Resistance : 100MΩ Min
4. Operating Force : 700gf Max
5. Life cycle : 10,000 steps

53

pdf

TER-10

TER-10旋转编码开关 10档立式插件旋转编码开关 0-10档旋转档位开关

SPECIFICATION
1. Rating : 150mA, 42V DC (Switching)
200mA, 42V DC (None-Switching)
2. Contact Resistance : 80mΩ Max
3. Insulation Resistance : 100MΩ Min
4. Operating Force : 700gf Max
5. Life cycle : 10,000 steps

188

pdf

TSR-10

TSR-10旋转编码开关 10档DIP立式插件编码开关，SUNGMUN旋转编码开关

SPECIFICATION
1. Rating : 150mA, 42V DC (Switching)
200mA, 42V DC (None-Switching)
2. Contact Resistance : 80mΩ Max
3. Insulation Resistance : 100MΩ Min
4. Operating Force : 700gf Max
5. Life cycle : 10,000 steps

176

pdf

TSR-16

TSR-16旋转编码开关，16档DIP旋转编码开关，0-16档插件编码开关，10*10旋转编码开关

SPECIFICATION
1. Rating : 150mA, 42V DC (Switching)
200mA, 42V DC (None-Switching)
2. Contact Resistance : 80mΩ Max
3. Insulation Resistance : 100MΩ Min
4. Operating Force : 700gf Max
5. Life cycle : 10,000 steps

183

pdf

UDR-10

UDR-10旋转编码开关，10档立式插件编码开关，0-10档DIP档位拨码开关

Specification
1. Rating : 25mA, 12V DC (Switching)
25mA, 24V DC (None-Switching)
2. Contact Resistance : 100mΩ Max
3. Insulation Resistance : 100MΩ Min
4. Operating Force : 700gf Max
5. Life cycle : 10,000 steps

134

pdf

UDR-16

UDR-16旋转编码开关，16档DIP插件编码开关，10*10立式插件编码开关

Specification
1. Rating : 25mA, 12V DC (Switching)
25mA, 24V DC (None-Switching)
2. Contact Resistance : 100mΩ Max
3. Insulation Resistance : 100MΩ Min
4. Operating Force : 700gf Max
5. Life cycle : 10,000 steps

147

pdf
